Electric water heater Electrolux EWH 100 QT EEC

Electric water heater Electrolux EWH 100 QT EEC

Full description

The design of the device may slightly differ from that presented on the site.

Series

QT EEC
Water heating time from 10°C to 75°C

318 min
Nominal volume

100 l
Max. power consumption

1.5 kW

Water heating time from 10°C to 75°C

318 min
Nominal volume

100 l
Max. power consumption

1.5 kW

Product documents

PDF Download PDF

Main

Inner coating of the tank: Enamel
Outer body material: Metal
Inner tank material: Enamelled steel
Nominal volume: 100 l
Heating element type: Tubular electric heater (TEH)
Case shape: Round
Case color: White
Series: QT EEC
Warranty period: 5 years for indoor capacity and 2 years for electrical components
Country of origin: PRC

Performance

Water heating time from 10°C to 75°C: 318 min
Min. water temperature: 30 °С
Max. water temperature: 75 °С
Ступени мощности нагрева: 1,50 kW

Indication

Rotate the display: no
Heating temperature display: no
Display type: no
Power on indication: yes

Mounting

Inlet thread: 1/2 inch
Outlet thread: 1/2 inch
Max. power consumption: 1.5 kW
Type of connection: Lower
Installation type (mounting): Indoor wall
Network cable: Yes (with plug)

Product weight and dimensions

Product height: 87.7 cm
Product width: 45 cm
Product depth: 45 cm
Product weight (net): 29.7 kg

Control

Thermostat type: Mechanical
Temperature control: Yes (mechanical regulator)
Control type: Mechanical
Temperature setting accuracy: Mechanical adjustment

Modes

Number of heating modes: 1

Protection and safety

Protection against switching on without water: no
Pressure relief valve: yes
Dust and moisture resistance class: IPX4
Anti-calc: Magnesium anode
Corrosion protection: Oversized magnesium anode
Overheat protection: yes
Fault self-diagnosis system: no

Ensemble

Set of fasteners included: yes

Packaging weight and dimensions

Product packaging height: 46.5 cm
Product packaging width: 50.5 cm
Product packaging depth: 100.5 cm
Product weight with packaging (gross): 32.4 kg

Data sheet

Product features
- Series

  QT EEC
- Water heating time from 10°C to 75°C

  318 min
- Nominal volume

  100 l
- Max. power consumption

  1.5 kW
Dry heating elements

Mechanical control

Effective thermal insulation

Multi-level protection of inner tank
Key characteristics
- Water heating time from 10°C to 75°C

  318 min
- Nominal volume

  100 l
- Max. power consumption

  1.5 kW
Product documents
Product documents
- PDF Download PDF
All characteristics
Main

Inner coating of the tank: Enamel

Outer body material: Metal

Inner tank material: Enamelled steel

Nominal volume: 100 l

Heating element type: Tubular electric heater (TEH)

Case shape: Round

Case color: White

Series: QT EEC

Warranty period: 5 years for indoor capacity and 2 years for electrical components

Country of origin: PRC
Performance

Water heating time from 10°C to 75°C: 318 min

Min. water temperature: 30 °С

Max. water temperature: 75 °С

Ступени мощности нагрева: 1,50 kW
Indication

Rotate the display: no

Heating temperature display: no

Display type: no

Power on indication: yes
Mounting

Inlet thread: 1/2 inch

Outlet thread: 1/2 inch

Max. power consumption: 1.5 kW

Type of connection: Lower

Installation type (mounting): Indoor wall

Network cable: Yes (with plug)
Product weight and dimensions

Product height: 87.7 cm

Product width: 45 cm

Product depth: 45 cm

Product weight (net): 29.7 kg
Control

Thermostat type: Mechanical

Temperature control: Yes (mechanical regulator)

Control type: Mechanical

Temperature setting accuracy: Mechanical adjustment
Modes

Number of heating modes: 1
Protection and safety

Protection against switching on without water: no

Pressure relief valve: yes

Dust and moisture resistance class: IPX4

Anti-calc: Magnesium anode

Corrosion protection: Oversized magnesium anode

Overheat protection: yes

Fault self-diagnosis system: no
Ensemble

Set of fasteners included: yes
Packaging weight and dimensions

Product packaging height: 46.5 cm

Product packaging width: 50.5 cm

Product packaging depth: 100.5 cm

Product weight with packaging (gross): 32.4 kg

Product information

Water heaters of the QT series, thanks to the classic round body, with a diameter of 34 cm, can be placed even in a small space.
Corrosion resistance is ensured by multi-level protection of all important structural elements of the Protect Tank: a finely dispersed enamel coating of the inner surfaces of the tank and an increased mass magnesium anode. The protection system — from overheating, from high hydraulic pressure and simple control make these devices a truly universal solution for the constant supply of hot water to the house.
